Description
Add extra punch to your sound system with the Next-Generation Alpine S-Series Subwoofers; now redesigned for powerful and reliable bass performance at an approachable price point.
Featuring the lightweight yet sturdy combination of carbon fiber and polypropylene, the Next-Gen S-Series Subwoofer cone delivers deep, low-distortion bass that enhances the depth and richness of your music.
With a power handling of 300W RMS and a peak power handling of 900W, the Next-Gen 8” S-Series Subwoofers deliver outstanding performance value. Boasting a wide frequency response range of 23Hz to 215Hz and a sensitivity of 83dB (1W/1m), these subs ensure powerful and accurate bass reproduction across a diverse range of music genres.
The Next-Generation S-Series Subwoofers contains Alpine’s High Amplitude Multi-Roll (H.A.M.R.) Surround Technology. This rubber surround allows the subwoofer cone to efficiently move air while staying cool. This technology allows for 13mm of one-way cone excursion and creates incredible accuracy from the subwoofer.
With 600W of RMS power, the S2-A60M Amplifier is power matched perfectly for two (2) S-Series 8” Subwoofers.
Delivering an impressive 1200W RMS of power at 1 and 2 ohm, the S2-A120M is the ideal solution to power up to four (4) Alpine S-Series 8” Subwoofers.
- Dual Voice Coil (DVC) Subwoofers with Configuration Jumpers
- Carbon Fiber/Poly Propylene Cone
- Twist-Lock Grille Mount System
- High-Amplitude Multi-Roll (H.A.M.R.) Surround
- Power Handling: 300W RMS / 900W Peak
- Nominal Impedance: 2Ω
- Frequency Response: 23Hz - 215Hz
- Sensitivity: 82.6dB
- X-Max (1-Way): 13mm
- Voice Coil: 1.4”
- Magnet Weight: 34oz
