Description
Superlative vinyl performance in a more compact size!
The Xtension 10 chassis is made from MDF filled with metal sand, that gives high mass and is non-resonant. Magnetic feet, which decouple the main plinth from its base, are combined with a weighty 22 kg total turntable mass. With these two magnets located in the feet, the turntable is practically floating.The result is a unique combination of ‘mass loaded’ and ‘floating turntable’ design principles. Instead of the old standard adoption of pure metal used for the main platter, we’ve found a perfect alloy which we damped on the inner side with Sorbothane®. Additionally we’ve glued recycled Vinyl records to the top (which act as a perfect mat) and bake this ‘sandwich’ before precision balancing it. The final product subsequently benefits from a wonderfully resonance-free, heavy platter, that runs ultrasilently on an inverted ceramic ball bearing with magnetic suspension. The Pro-Ject 10” Evolution with its tonearm base also benefits from ‘high-mass’ technologies, and is isolated from the main board by a sheet of Sorbothane®. To use this tonearm with a wide range of top quality phono cartridges, from 4 to 14 Grams it comes with a set of 4 different Sorbothane®- damped counterweights.
The Xtension 10 Evolution comes standard with the premium tonearm cable 5pin > RCA cable. For an optimal connection to the Phono Box RS or RS2, the symmetrical premium tonearm cable 5pin > XLR is available separately. Phono Box RS and RS2 offer balanced phono inputs, what guarantees superior results in high-end vinyl reproduction with a balanced signal source.
NOTE: The signal source and the receiving device have to be equipped with balanced connections. Transmission of audio signals in a balanced mode reduce the influence of interference due to external stray electric fields significantly.
In the box:
- Xtension 10 Evolution optionally as SuperPack with Ortofon Cadenza Black
- Connect it 5P-C RCA Cable (Upgrade option: 5P-XLR)
- Dust cover
- Adapter for 7“ singles
- Record puck
- Counterweights for 4-14g cartridges
- Power supply, allen key, spirit level, gloves
